Purely importedHQ grapheneMuscovite crystals
$416.67
Grade V1 purity, ~25×25×0.15 mm. Excellent electrical insulation, thermal stability, and van der Waals exfoliation. Ideal for capacitors, industrial insulation, coatings, and cosmetics.
-
Structure: Monoclinic (a=0.519 nm, b=0.901 nm, c=1.996 nm)
-
Packaging: 5 pieces/box
-
Applications: Electronics, insulation, pigments, 2D research
Email: sales@maxnanotech.com
Important Notes
- No Refunds or Exchanges: All sales are final. MAXNANO does not provide return, exchange, or refund services under any circumstances.
- Customs and Import Obligations: Clearance procedures, import duties, taxes, and related costs are solely the responsibility of the recipient/importer. MAXNANO shall not be held liable for delays, rejections, or any additional expenses incurred during customs processes. Such issues shall not constitute grounds for order cancellation or refund.
- Order Cancellation: Orders cannot be revoked once submitted. No refunds will be issued for cancelled or undelivered orders.
- Indemnification: The purchaser agrees to bear all claims, losses, legal liabilities, and expenses arising from the use of products and services, and shall hold MAXNANO, its affiliates, and personnel harmless from such obligations.
- Terms and Conditions: All orders and business interactions are subject to MAXNANO’s standard Terms and Agreements.
Inquiry Now
Product Overview
We supply high-quality natural muscovite mica crystals from HQ Graphene, featuring exceptional electrical insulation properties and perfect van der Waals layered structure. These naturally formed crystals exhibit excellent thermal stability and electrical insulation, making them ideal for electronic, industrial, and specialized applications.
Specifications
-
Type: Natural crystal
-
Purity: Grade V1 (99.995%)
-
Size: ~25 × 25 × 0.15 mm
-
Crystal Structure: Monoclinic
-
Unit Cell: a = 0.519 nm, b = 0.901 nm, c = 1.996 nm
-
Angles: α = γ = 90°, β = 95.89°
-
Packaging: 5 pieces/box
Key Properties
-
Excellent Electrical Insulation: Ultra-high breakdown voltage
-
Thermal Stability: Maintains properties at high temperatures
-
Van der Waals Structure: Easy exfoliation to 2D layers
-
Chemical Inertness: Resistant to most chemicals
-
Mechanical Flexibility: Can be split into thin, flexible sheets
Product Features
-
Natural crystalline formation
-
Large rectangular morphology
-
Perfect cleavage planes
-
High dielectric strength
-
Consistent quality across batches
Applications
Electronic & Electrical Industry
-
Mica capacitors for aerospace and military devices
-
Motor and generator insulation components
-
Rectifier commutator insulation
-
High-voltage insulator production
-
Terminal blocks and insulating washers
Industrial Manufacturing
-
Mica paper for electrical insulation
-
Large generator insulating materials
-
High-temperature insulation for household appliances
-
Automotive and armored vehicle insulation systems
-
Epoxy-based composite insulating tapes
Coatings & Pigments
-
White pigment for paints and coatings
-
Enhanced brightness and opacity additive
-
Long-lasting color retention in coatings
-
Special effect pigment applications
Cosmetics
-
Eye shadow and makeup shimmer effects
-
Lipstick sparkle additive
-
Nail polish special effects
-
Cosmetic glitter applications
Research Applications
-
2D material exfoliation studies
-
Insulating material research
-
Van der Waals heterostructures
-
Surface science investigations
Technical Advantages
-
Superior to synthetic insulating materials
-
Excellent high-temperature performance
-
Natural material with consistent properties
-
Easy processing and exfoliation
-
Custom sizes and thicknesses available
Quality Assurance
-
Crystalline structure verification
-
Electrical insulation testing
-
Thermal stability assessment
-
Chemical composition analysis
-
Batch consistency certification
Contact Information
For technical specifications and ordering:
Email: sales@maxnanotech.com
| Weight | 100 g |
|---|---|
| Dimensions | 30 × 20 × 20 mm |
| Specification | Purity: 99.995% |
