CVDCopper-based graphene film5cmx5cm

Overview
CVD graphene synthesis relies on three essential elements: substrate selection, carbon precursor gases, and optimized growth conditions. Copper foil serves as an ideal substrate for graphene growth due to its catalytic surface behavior and self-limiting growth mechanism, which promotes the formation of large-area, high-quality monolayer graphene. This product provides graphene directly on a 5 cm × 5 cm copper foil, ready for transfer to desired substrates or direct use in certain applications.

Specifications

• Substrate: Copper foil

• Copper Thickness: ~25 µm

• Graphene Area: 5 cm × 5 cm

• Available Layers: Monolayer, Bilayer, 3–5 Layers, 6–8 Layers

Key Features

• High Crystallinity and Uniform Coverage: Ensures consistent electronic and mechanical performance

• Excellent Electrical Properties: High carrier mobility and low sheet resistance

• High Optical Transparency: Suitable for optoelectronic applications

• Outstanding Mechanical Flexibility and Strength: Ideal for flexible electronics and composites

• High Chemical Stability: Performs reliably under ambient conditions

Applications

• Electronic Devices: Field-effect transistors, integrated circuits, and flexible electronics

• Optoelectronics: Transparent conductive films, touch screens, and light-emitting devices

• Sensors: Highly sensitive chemical and biological detection platforms

• Energy Systems: Electrodes for solar cells, supercapacitors, and batteries

• Advanced Composites: Used as a functional interface to enhance material properties

Note
Customers may specify pretreatment requirements:

• PMMA spin-coating on the graphene side for protection

• Back-side copper etching for partial or full transfer

• Default service includes PMMA coating, etching, and transfer to a silicon oxide substrate, accompanied by Raman quality analysis.
