3-5Layer graphene electron microscope grid (carbon grid)

Overview
This product features 3-5 layer CVD graphene transferred onto 300-mesh lacey carbon TEM grids. Grown via chemical vapor deposition on copper substrates, these few-layer graphene samples exhibit uniform layer stacking and excellent crystalline quality. The lacey carbon support provides optimal stability for TEM characterization while allowing for high-resolution imaging of the graphene layers and their interfaces.

Specifications

• Support Grid: 300-mesh Lacey Carbon

• Graphene Layers: 3-5 layers

• Growth Substrate: Copper foil

• Transfer Method: PMMA-assisted process

• Packaging Options: 5 or 10 pieces per package

Key Features

• Controlled Layer Number: Uniform 3-5 layer structure ideal for comparative studies

• High Crystallinity: Maintains excellent electronic and mechanical properties

• Optimal Support: Lacey carbon provides stability while maximizing imaging areas

• Research Ready: Pre-mounted on TEM grids for immediate use

• Reliable Performance: Consistent quality across all samples

Applications

• Layer-Dependent Studies: Investigation of electronic and optical properties across different layer numbers

• Interface Characterization: Analysis of layer interactions and stacking behavior

• Materials Research: Support for nanoparticle studies and hybrid material investigations

• Educational Use: Excellent samples for teaching TEM operation and graphene characterization

• Quality Control: Reference material for graphene production and transfer processes

Note

• Minor catalyst residues may appear as dark spots under TEM – normal byproduct of CVD process

• Optional dilute acid treatment available for reduced residue visibility

• Store in dry conditions at room temperature
